Honda F18 engine

Honda F18 engine (1989-2003)



The Honda F18 type engine is an in-line 4-cylinder gasoline engine for medium-sized vehicles manufactured by Honda Motor Co., Ltd from 1989 to 2003.

History

F18A (SOHC) were adopted for the first time in the 4th generation Accord and 1st generation  Rover 618 and Ascot first announced on September 13, 1989. It is the successor to the A-type, and is a sibling design to the H-type.Equipped with two intake and exhaust valves, and a spark plug was placed in the centre of the ceiling of the combustion chamber. In addition, the SOHC specification tilts the upper side toward the intake valve in order to avoid the camshaft. The aluminium die -cast cylinder block with four-cylinder bores adopts a deep skirt shape to increase the support rigidity of the crankshaft. A balancer was also installed to reduce the vibration of the secondary engine.The F18 engine was used until 5th generation Accord upto 2003.

SOHC F18A

The line-up includes carburettor (downdraft, fixed venturi) and PGM -FI (multi-point intake manifold injection) specifications. A variable intake system is adopted for the intake manifold.

Valve mechanism: SOHC belt drive
Valves: 16 valves
Displacement: 1,849cc
Bore x Stroke: 85.0mm x 81.5mm (3.35 in × 3.21 in)
Fuel supply device type: carburettor
Reference specs (CB1 Accord)
Maximum output: 77 kW (105 PS) / 6,000 rpm
Maximum torque: 143 N m (14.6 kg. m) / 4,000 rpm

Installed vehicles

Rover 618i ,Accord (CD3), Ascot (CB1/2)

Honda F18 engine specifications (1989-2003)

SOHC VTEC F18B

It is equipped with a variable valve timing lift mechanism for the purpose of achieving both high output and practicality. Two types of cam pieces are provided only on the intake side camshaft, and the swing arm that contacts there is switched to change the opening and closing timing of the intake valve (valve timing) and the amount of lift. There is a specification similar to " VTEC-E ", which performs lean burn operation with one side almost inactive. Furthermore, a roller is applied to the sliding part of the rocker arm came to reduce friction.

Although it is only for PGM-FI specifications, AAI (air assist injector) that supplies secondary air from the intake manifold to some specifications to promote fuel atomization and a swirl port that functions when the intake valve is inactive. is equipped with in addition, an electric EGR valve is used to increase the EGR flow rate and control it with high accuracy, thereby reducing NOx emissions and improving fuel efficiency.



Valve mechanism: SOHC VTEC belt drive
Firing order 1-3-4-2
Compression ratio: 9.0:1-10.0:1
Valves: 16 valves
Displacement: 1,849cc
Bore x Stroke: 85.0mm x 81.5mm
Fuel supply device type: Electronically controlled fuel injection type (PGM-FI)
Reference specs (CF3 Accord)
Maximum output from : 103 kW (140 PS) / 6,100 rpm
Maximum torque from: 169 N m (17.2 kg. m) / 5,000 rpm



Installed vehicles (1993-2003)

European (CG8,CH6) Accord, Torneo (CF3), Japan Accord (CD3),Isuzu Aska (CJ2)

Honda F18 engine (1989-2003)

Categories
Honda Engines | Rover Engines | Isuzu engines
Title
Honda F18 engine (1989-2003)

Description

Have you Say: Rate this
Overall Vote
  • 1
  • 2
  • 3
  • 4
  • 5
1. Performance & Specification
  • 1
  • 2
  • 3
  • 4
  • 5
Built to last?
2. Appearance Overall *Cool factor*
  • 1
  • 2
  • 3
  • 4
  • 5
How good it looks ?
Related items
Honda Ascot | Honda Torneo | Isuzu Aska | Rover 600 Series | Rover Related | Honda related | Petrol Engines | Straight-4 Engines

Technical

Technical
  • Honda F18 engine Technical details and specifications (1989-2003)

    Honda 1.8L Engine: F18A

    No. of cylinders4/OHC
    Capacity 1849 cc
    Compression ratio 9,0:1
    Ignition system Type TSZ-i
    Fuel system Make Keihin Carb-2V
    Diagnostic socket No
    Ignition coil Make Hitachi
    Firing order 1-3-4-2
    Distributor Make Hitachi
    Oil pressure 3.4 bar @ 3000 rpm
    Thermostat opens 78±2°C
    Fuel system delivery pressure 0.09-0.14 bar

    Honda 1.8L Engine F18B

    No. of cylinders 4/OHC
    Capacity 1850 cc
    Firing order 1-3-4-2
    Compression ratio 10.0:1
    Ignition fuel system Make Honda PGM-FI
    Air metering Type MAP
    Combined ignition and fuel ECM Yes
    Diagnostic socket Yes
    Oil pressure 3.5 bar@ 3000 rpm
    Radiator cap 0.93-1.23 bar
    Thermostat opens 76-80°C
    Fuel system pressure 2.8-3.3 bar
    Maximum cranking amps 149-182 A
    Injector 11-20 Ohm

    © Motor car History

Service
  • Honda F18 engine Maintenance and Service Guide (1989-2003)

    Honda 1.8L Engine: F18A

    Spark plugs Electrode gap 1.0-1.1mm
    Spark plugs Original equipment NGK Type ZFR6F-11
    Spark plugs Make Bosch Type FR7LCX
    Spark plugs Make Champion Type RC9YCC4
    Spark plugs Make NGK Type ZFR6F-11
    Valve clearance -INLET 0.24-0.28 check cold
    Valve clearance -EXHAUST 0.28-0.32mm check cold
    Engine oil grade - normal/moderate climate 10W/40 SAE 15W/40 SAE
    Engine oil grade - cold climate 5W/30 SAE
    Engine oil grade - hot climate 20W/40 SAE
    Engine oil change with filter 3.8 litres
    Cooling system 6.6 litres

    Honda 1.8L Engine F18B

    Spark plugs Original equipment Denso Type KJ20CR-L11
    Spark plugs Electrode gap 1.1 mm
    Spark plugs tighten 18 Nm
    Spark plugs Make NGK Type ZFR6F-11
    Valve clearance -INLET 0.24-0.28mm check cold
    Valve clearance -EXHAUST mm 0.28-0.32mm check cold
    Engine oil grade - normal/moderate climate 10W/40 SAE or 15W/40 SAE
    Engine oil grade - cold climate 5W/30 SAE
    Engine oil grade - hot climate 20W/40 SAE
    Engine oil change with filter 4.4 litres
    Engine oil Sump drain bolt tighten 44 Nm
    Engine oil Oil filter tighten 22 Nm
    Cooling system 5.8 litres

    Cylinder head Tightening torques (Renew bolts)
    Stage 1 Tighten 29 Nm
    Stage 2 Tighten 90°
    Stage 3 Tighten 90°
    Stage 4 Tighten 90°
