Ford Crown Victoria 2nd generation (EN114)

Ford Crown Victoria 2nd generation Service Guide (EN114)

Model years

1998 to 2012

Engine

4.6 L 2v SOHC  V8

Transmission

4-speed automatic

Wheelbase

114.7 in (2,913 mm)
120.7 in (3,066 mm) (LWB)

Length

212.0 in (5,385 mm)
219.0 in (5,563 mm) (LWB)

Width

77.3 in (1,963 mm)

Height

56.8 in (1,443 mm)

Curb weight

4,057 lb (1,840 kg)



In autumn 1997, a new generation of the Crown Victoria was introduced. It was based much more on the parallel model Mercury Grand Marquis. For example, the front section with the indicated radiator grille was adopted by the same as the roof with a wider C-pillar. Only for taxi companies and only in the US in 2002 appeared a version with a longer wheelbase. In the middle of 2003, this model generation experienced a facelift.

The model was offered until August 2011 for the police, the fire department and taxi companies and after the recruitment of the Mercury Grand Marquis in a civilian rental car version. In the last model generation, the Crown Victoria has a wheelbase of 2.91 m and a total length of 5.38 m. The Crown Victoria is powered by a 4.6-liter eight-cylinder gasoline engine, which makes depending on the model variant between 224 and 239 hp.

Ford Crown Victoria 2nd generation (EN114)

The consumption of civilian models was stated by Ford at between 25 and 17 miles per gallon, which corresponds to 9.4 to 13.8 litres per 100 km.

With closure of the plant in St. Thomas (Ontario) on Lake Erie on 31 August 2011, production of the Panther platform was North America set. There is no direct successor to the Crown Victoria. The next smaller model, the Ford Taurus is thus since then the largest sedan in the North American Ford model range.

Ford Crown Victoria 2nd generation Technical details and specifications (EN114)

For the American police as well as taxi companies, in which the Crown Victoria was very popular, special designs were made with higher performance. In New York, the Crown Victoria in the taxi version with a share of about 90 percent as the last full-size model dominated the cityscape of the metropolis for a long time. Since the end of 2013, a Nissan NV200 taxi version has replaced the Crown Victoria. Key reasons why Crown Victoria continues to be so popular with the police and taxi companies are the above-average reliability and low maintenance costs. Despite recent miserable sales figures in the private sector, the Crown Victoria has received regular awards as "Best Used Car Bet" by various specialist publications.

Ford Crown Victoria 2nd generation (EN114)

Related items
Ford Crown Victoria | Vehicles launched in 1997 | American 1990s | American 2000s

Rating

Have you Say: Rate this
Overall Vote
80% - 1 vote
  • 1
  • 2
  • 3
  • 4
  • 5
1. Performance & Specification
80% - 1 vote
  • 1
  • 2
  • 3
  • 4
  • 5
Built to last?
2. Appearance Overall *Cool factor*
80% - 1 vote
  • 1
  • 2
  • 3
  • 4
  • 5
How good it looks ?

Technical

Technical
  • Technical data Ford Crown Victoria

    Ford Crown Victoria

    4.6

    Engine:

    8-cylinder V-engine (four-stroke), bank angle 90 °

    Displacement:

    4606 cm ³

    Hole × Hub:

    90.2 × 90 mm

    Performance at 1 / min:

    167 kW
    (224 hp)
    at 4800

    Max. Torque at 1 / min:

    359 Nm at 4000

    Compression:

    9.4: 1

    Mixture preparation:

    Electronic injection

    Valve control:

    OHC, Chain, 2 valves per cylinder

    Cooling:

    Water cooling

    Gearbox:

    Four-speed automatic
    Rear wheel drive

    Front wheel suspension:

    Double triangle handlebars, coil springs

    Back suspension:

    Rigid axle, longitudinal and inclined handlebars, watt rods, coil springs

    Brakes:

    All-round ventilated disc brakes (diameter v / h 30.5 / 29.2 cm), brake booster, ABS

    Steering:

    Rack of teeth steering, servo supported

    Body:

    Sheet steel, on conductor frame

    Front / rear track width:

    1610/1660 mm

    Wheelbase:

    2915 mm
    LWF: 3068 mm

    Dimensions:

    5385 × 1985 × 1480 mm
    LWF: 5540 × 1985 × 1480 mm

    Empty weight:

    from 1860 kg

    Top speed:

    approx. 225 km / h

    0 – 100 km / h:

    n. a.

    Consumption (Liter / 100 kilometres, EPA standard city traffic):

    13.1 p

    Ford Crown Victoria

    4.6 HO

    Engine:

    8-cylinder V-engine (four-stroke), bank angle 90 °

    Displacement:

    4606 cm ³

    Hole × Hub:

    90.2 × 90 mm

    Performance at 1 / min:

    178 kW
    (239 hp)
    at 4900

    Max. Torque at 1 / min:

    390 Nm at 4100

    Compression:

    9.4: 1

    Mixture preparation:

    Electronic injection

    Valve control:

    OHC, Chain, 2 valves per cylinder

    Cooling:

    Water cooling

    Gearbox:

    Four-speed automatic
    Rear wheel drive

    Front wheel suspension:

    Double triangle handlebars, coil springs

    Back suspension:

    Rigid axle, longitudinal and inclined handlebars, watt rods, coil springs

    Brakes:

    All-round ventilated disc brakes (diameter v / h 30.5 / 29.2 cm), brake booster, ABS

    Steering:

    Rack of teeth steering, servo supported

    Body:

    Sheet steel, on conductor frame

    Front / rear track width:

    1610/1660 mm

    Wheelbase:

    2915 mm
    LWF: 3068 mm

    Dimensions:

    5385 × 1985 × 1480 mm
    LWF: 5540 × 1985 × 1480 mm

    Empty weight:

    from 1860 kg

    Top speed:

    approx. 225 km / h

    0 – 100 km / h:

    n. a.

    Consumption (Liter / 100 kilometres, EPA standard city traffic):

    13.1 p
