Multicar History

Multicar History

resolution

2005

Seat

Waltershausen , Gotha , Thuringia , Germany

business

commercial vehicles



Multicar is a model series designation for commercial vehicles of Hako GmbH , which are manufactured in the branch factory in Waltershausen . The company Multicar has merged into Hako and is part of the Possehl Group. Multicar is now the only existing motor vehicle brand from the former GDR .

History

In 1920, the present company was founded as ADE-Werke . There were agricultural equipment, vehicle trailers and trailer hitches for trucks and tractors produced. After the Second World War , production was resumed in 1946 as Gerätebau Waltershausen .

In 1948 the company was named VEB Fahrzeugwerk Waltershausen , which it carried until its privatization in 1991. The original diesel ant DK 2002 was manufactured from the year 1951 in the VEB Brand-Erbisdorf . The vehicle was designed for the yard transport, made 5.6 hp and the steering was done by means of foot pedal in the open cab.  1956, the production of diesel ant DK 3 was added, which had previously been built in Ludwigsfelde and Brand-Erbisdorf. In addition to the flatbed version , the vehicle was already available as a dump truck and three-way tipper .1958, the first multicar was produced, which also still foot-steered M21 . By 1964, 14,000 had left the factory in Waltershausen. The following ten years 42,500 vehicles of the M 22 series ranoff the line.

By 1978, the successor M 24 was produced, of which 25,659 copies (of which 48% for export) left the factory. The M 25 was an export hit; 70% of the vehicles went to the states of the CMEA and to the west. In the UK, a two-way vehicle was built in cooperation with Harsco -Permaquip. The production of the M 25 was continued in 1991 with VW engine. About 100,000 pieces were produced. In 1991, the state-owned plant was privatized. Decisive driving force in the turnaround- and reunification was the former director of materials management at Multicar, Manfred Windus, who was named Manager of the Year in 1993. From 1993 to 2010, the successor model M 26 was produced.

In 1998, Hako-Werke took over the shares of Deutsche Beteiligungsgesellschaft and thus became the majority shareholder. The products TREMO (formerly Kramer ) and UX 100 (formerly Unimog 409 ) were merged in Waltershausen. In 2001, the construction of the new series began M30 Fumo ( Fu nction and Mo bility). In cooperation with Krauss-Maffei Wegmann , since 2004 the special vehicle ESK Mungo has been used for the Bundeswehrmanufactured. By 2009, the production of 396 vehicles was planned. Despite appearing deficiencies and appropriate criticism in the troop, additional vehicles were ordered in 2009 and 2011.

In 2005, the company was merged with Hako-Werke GmbH as the acquiring company, the company dissolved and Multicar was only a trademark of Hako. Since spring 2013, Multicar has only been managed as a product series under the umbrella brand Hako . The product range comprises since 2017 four civilian models: M27compact , M29, M31 and M31H

Current and recently discontinued series

The M 31 series has been fitted with E6 emission standards since 2015. The products M 27 , FUMO , the particularly narrow TREMO and partly the M 31 series are equipped with engines homologated according to Euro 5 standard . Multicar depends, inter alia on two different common rail - diesel engines .

On the one used in the models M 27 and TREMO the Volkswagen - four-cylinder diesel engine is EA 189 in model CJDA as a drive, which is at 3000 min -1 to 75 kW (102 hp) brings and in similar form in facegelifteten VW Crafter , the VW T5 and in numerous car models of the VW Group ( VW , Audi , Škoda , Seat ) under the name 2.0 TDI is used. The maximum torque of this motor is of 285 Nm at 1750 min -1on. In addition to the Euro 5 version, the TREMO and M 27 series are also available in the previously unlisted EEV homologation .

On the other hand, the FUZO and M 31 series are equipped with the F1C diesel engine from Fiat Powertrain Technologies ( Iveco / FPT F1C). Like the VW engine is also in this Euro 5 and EEV certification available and provides in versions Tipper , body and carrier 107 kW (145 hp) at 3500 min -1 and 320 Nm at 1400 min -1 , in the Carrier H, however, he comes to 90 kW (122 hp) at 3000 min -1 (310 Nm at 1400 min -1 ). It is used identically in the Iveco Daily .



Categories
Germany | Multicar
Title
Multicar History (1920-2005)

Description

Have you Say: Rate this
Overall Vote
  • 1
  • 2
  • 3
  • 4
  • 5
1. Performance & Specification
  • 1
  • 2
  • 3
  • 4
  • 5
Built to last?
2. Appearance Overall *Cool factor*
  • 1
  • 2
  • 3
  • 4
  • 5
How good it looks ?
Related items
Multicar Related | German Automotive 1990s | German Automotive 1970s | Commercial vehicles

Technical

Technical
  • Nulticar engines overview:

    model

    engine type

    capacity

    Bore × stroke

    design type

    Fuel supply

    power

    torque

    comment

    M 27

    VW EA 189
    (model CJDA)

    1968 cm³

    81 mm × 95.5 mm

    Series 4
    4 valves

    Common rail - direct injection

    75 kW (102 hp)
    at 3500 min -1

    250 Nm
    at 2600 min -1

    Particle filter
    (closed system)

    TREMO

    75 kW (102 hp)
    at 3000 min -1

    285 Nm
    at 1750 min -1

    FUMO

    Iveco F1C

    2998 cc

    95.8 mm × 104 mm

    107 kW (145 hp)
    at 3500 min -1

    320 Nm
    at 1400 min -1

    90 kW (122 hp)
    at 3000 min -1

    310 Nm
    at 1400 min -1

    M 31

    107 kW (145 hp)
    at 3500 min -1

    320 Nm
    at 1400 min -1

    90 kW (122 hp)
    at 3000 min -1

    310 Nm
    at 1400 min -1

    Transmission variants The three current series are available in different transmission configurations. In addition to a 5-speed manual transmission (four-wheel version with 10-speed manual gearbox), the FUMO model series also includes a two-speed hydrostatic transmission with variable speed control. The 5- or 10-speed manual transmission is also available for the M 27 , while the TREMO is only available with a continuously variable transmission .
