Pontiac Executive
![]() | |
Manufacturer | Pontiac (GM) |
Production | 1966 to 1970 |
Class | Motor Car |
Body style | 2-4 door hardtop |
Platform | B-body |
Engine | 400 cu in (6.6 L) V8 |
Transmission | 3-4 speed manual |
Wheelbase | 1965-68: 124 in (3,150 mm) |
Length | 1965-68: 222.6 in (5,654 mm) |
Width | 79.7 in (2,024 mm) |
The Pontiac Executive was a mid -range model built by American automaker Pontiac, which was offered from 1967 to 1970.
1966 had the predecessor Star Chief already the nickname Executive, so in 1967 this name became the actual model’s name. Between the simpler equipped Catalina and the luxurious Bonneville, the executive took the middle spot in the range of "full-size" automobiles. The cars showed the design typical for the late 1960s at Pontiac with a wide grille with painted centre bar and superimposed twin headlights. The fashionable "Coke-Bottle-Design" (first tested in the Chevrolet Corvair 1965) manifested itself in a hip type kink over the rear wheel cutouts.
With the larger wheelbase, a 4-door sedan and two hardtop versions with 2 or 4 doors were available. The 5-door station wagon with six or nine seats had, like all Pontiac station wagons at this time, a 3 "smaller wheelbase and was nicknamed Safari. The engine was powered by a V8 engine with 6555 cc of displacement, which at 4600 rpm had an output of 265 bhp (195 kW).
PERFORMANCE: 400 cu in
- max power (SAE): 290 hp at 4,600 rpm
- max torque (SAE): 428 1b ft,59.1 kg m at 2,500 rpm
- max engine rpm: 4,600
- specific power: 44.2 hp/l
- Fuel consumption: 15.3 m/imp gal, 12.8 mlUS gal, 18.4 1 x 100 km
- Max speed:111 mph, 178.7 km/
- max speeds: 59 mph, 95 km/h in 1st gear; 100 mph, 161 km/h in 2nd gear; 111 mph, 178.7 km/h in 3rd gear; power-weight ratio: 14.5 lb/hp, 6.6 kg/hp;
- speed in direct drive at 1,000 rpm: 32.1 mph,51.7 km/h.
1968 changed the front view of the car clearly: Instead of the superimposed double headlights, there was now a little further inwardly offset a swing rear gate on the station wagon Safari. Price New in USA $ 3,653. Technical changes were not recorded this year, but now were on request also more powerful engines to choose:
- 6555 cc capacity of 330 hp (243 kW) at 4800 rpm
- 6555 cc capacity of 340 hp (250 kW) at 4800 rpm
- 6555 cc capacity of 350 hp (257 kW) at 5000 rpm
- 6555 cc with 360 hp (265 kW) at 5100 rpm
- 6555 cc displacement with 366 bhp (269 kW) at 5400 rpm
- 7014 cc displacement with 375 bhp (276 kW) at 4800 rpm
- 7014 cc displacement with 390 bhp (287 kW) at 5200 rpm
During those two years, 68,088 long-wheelbase limousines and coupes and 23,534 short wheelbase coupes were built.
There were no major changes in the appearance of the vehicles in 1969, but the wheelbases were increased by 1 "each, while the base V8 engine now produced 290 bhp (213 kW) at the same displacement.
1970 was again a major facelift. The cars now had double headlights arranged side by side in rectangular boxes, and the radiator grille consisted of two vertically arranged grid surfaces, which together with the wide, chrome-plated centre bar formed a bulky, protruding nose. The wide taillights (coupe and sedans) were offset in the rear bumper. Technically, there were no changes this year.
In 1969 and 1970, 47,781 long-wheelbase limousines and coupés and 23,706 short-wheelbase coupes were built. The executive station wagons were without successors; the sedans and coupes were from 1971 Catalina Brougham.
Variations optional equipment
- central gear lever; limited slip final drive 2.410 axle ratio
- power-assisted steering,3.50 turns of steering wheel lock to lock
- adjustable tilt of steering wheel
- servo brake; front disc brakes (diameter 11.80 in, 300 mm), internal radial fins, servo, total area rubbed by linings 360 sq in, 2,322 sq cm
- 70 Ah battery
- 8.45/8.85 x 14 H70 x 15 tyres
- cleaner air system
- air conditioning system
- Turbo-Hydramatic automatic gearbox, 3.230 3.080 2.560 axle ratios
Total by year
- 1967: 35,491 units
- 1968: 32,597 units
- 1969: 25,845 units
- 1970: 21,936 units
Rating
Technical
-
DIMENSIONS AND WEIGHT (1968 Executive Hardtop)
wheel base: 124 in, 3,150 mm
front track: 63 in,1,600 mm
rear track: 64 in, 1,626 mm
overall length: 223.50 in, 5,677 mm
overall width: 79.80 in, 2,027 mm
overall height: 54.80 in, 1,392 mm
ground clearance:5.80 in, 147 mm
dry weight: 4,244 1b, 1,925 kg
ENGINE: 400 cu in
location front
4 stroke; cylinders: 8, Vee-slanted at 90°
bore and stroke: 4.12 x3.75 in, 104.6 x 95.2 mm
engine capacity: 400 cu in, 6,554.80 cu cm
compression ratio: 10.5
cylinder block: cast iron
cylinder head: cast iron
crankshaft bearings: 5
valves: 2 per cylinder, overhead, in line, push-rods and rockers, hydraulic tappets
camshafts:1, at centre of Vee
lubrication: gear pump, full flow filter
lubricating system capacity: 11.62 imp pt, 14 US pt
carburation: 1 Rochester 7028066 downdraught twin barrel carburettor
fuel feed: mechanical pump
cooling system: water
TRANSMISSION
driving wheels: rear
gearbox: Turbo-Hydramatic, hydraulic torque convertor and planetary gears with 3 ratios
gearbox ratios: I 2.480, II 1.480, III 1, rev 2.080
selector lever: steering column
final drive: hypoid bevel
axle ratio: 2.560.CHASSIS
channel section perimeter ladder frame
front suspension: independent,wishbones, lower trailing links, coil springs, anti-roll bar, telescopic dampers
rear suspension: rigid axle, lower trailing links, oblique upper torque arms, coil springs, telescopic dampers.STEERING
recirculating ball
turns of steering wheel lock to lock: 5.60.
turning circle (between walls): 47 ft,14.3 mBRAKES
drum, dual circuit
area rubbed by linings: total 362.90 sq in, 2,340.70sq cm.ELECTRICAL EQUIPMENT
voltage: 12
battery 53 Ah
generator type: alternator, 42 Ah
ignition distributor: Delco-Remy
headlamps: 4.
-
fuel type: 99 oct petrol
engine sump oil 400 cu in: 10.03 imppt, 12 US pt, 5.7 1, SAE 5W-20 (winter) 10W-30 (summer), change every 6,000 miles,9,700 km
gearbox oil: 15.84 imp pt, 19 US pt, 9 1, ATF Dexron
final drive oil: 3.70imp pt, 4.50 US pt, 2.1 1, SAE 80-90
cooling system capacity: 29.92 imp pt, 36 US pt
valve timing 400 cu in: inlet opens 30° before tdc and closes 63° after bdc, exhaust opens 77° before bdc and closes 25° after tdc
normal tyre pressure: front 24 psi, 1.7 atm, rear 32 psi, 2.2 atm.
width of rims: 6"
tyres: 8.55 x 14
fuel tank capacity: 22 imp gal, 26.5 US gal
carrying capacity: 1,058 1b, 480 kg© Motor car History
