Renault Trafic I

Renault Trafic I history (1981-2000)
Make  Renault
Years of production Phase 1: 1981 - 1989
Phase 2: 1989 - 1994
Phase 3: 1994 - 2000
Production Approximately 950,000 copies
Classroom Light utility
Assembly plant (s)  Creil
Fuel Gasoline , diesel
Motor (s) Petrol
Cleon-Cast iron :1 397  cm 3
Cleon-Alu :1 647  cm 3
F :1 721  cm 3
Douvrin 1 995  cm 3 2 165  cm 3
Diesel
 F :1 870  cm 3
Douvrin  :2 068  cm 3
8140 Sofim :2,445  cm 3
Engine position Longitudinal before
Gearbox Manual at 4 or 5 speeds
Unloaded weight 1,200 to 1,300 kg
Bodywork (s) Van
Dropside
Micro-car
cab chassis
Length from 4,335 to 4,832 mm
Width from 2 110 to 2 150 mm
Height from 1,965 to 2,428 mm
wheelbase from 2,800 to 3,200 mm

The Renault Trafic I is a light utility van manufactured by Renault from 1980 to 2000. It was later restyled in 1989 and 1994. Trafic replaces the previous Estafette model .

Trafic modernized the light utility concept by offering traction (T) or propulsion (P) versions from March 1981 (traction is used to lower the height of the loading floor and propulsion provides better traction when the vehicle is in motion). is loaded) available in multiple variants ( sheet , glazed , raised, extended, tarpaulin or motorized) offering payloads ranging from 800 to 1400  kg (ie GVWs ranging from 2.1 tonnes to 3 tonnes). from the Renault 18 and 20 to gasoline or diesel , the latter engine missing from its Estafette predecessor. On the other hand, the rear axle is now rigid.During its long commercialization, it undergoes two restyles  (front face and dashboard ) and was the subject of many technical modifications (engines, mechanical elements, comfort and safety equipment).
Renault Trafic I Repair Manuals (1981-2000)

For 1985, the new 4x4 version receives a four-wheel drive drivetrain.

Phase I Traffic was launched in September 1980.
Phase II (1989 - 1994)
Phase III (1994 - 2000)

1994  : An agreement is signed with the Chinese manufacturer Sanjiang to build this model that will last 9 years,Early 1997  : part of the production is bought by GM . Traffic becomes Opel Arena or Vauxhall Arena. In Brazil , it's called Chevrolet Space Van.The different versions,Bus from 1980 to 2001.Platform / Chassis version from 1980 to 2001 and Van version from 1980 to 2001
Renault Trafic I  specifications(1981-2000)

Renault Previous 77 / 84 Next

Related

Related items
Alfa Romeo 8C Competizione | Renault Trafic | France 1990s | France 1980s | Vehicles launched in 1981 | Vans

Technical

Technical
  • Designation

    Letter Family Body Engine
    T = Traction
    P = Propulsion
    V = Integral
    1 = MT * - 800 kg - short
    4 = MT * - 1000 kg - long
    5 = TP ** - <9 seats - short


    TM *: Transport of goods
    TP **: Transport of persons
    1 = normal
    2 = raised
    3 = Mixed
    4 = Mixed raised
    5 = normal
    6 = Raised
    9 = floor / chassis only
    0 = Renault 847 - C1J
    1 = 841 / A1M
    2 = 829 / J5R
    3 = Renault 852 - J8S
    4 = S8U - 8140
    8 = F1N
    A = J7T
    B = S8U - 8140

    Bus Version 1980 to 1989

    Diesel

    • 2.1 D: 58 ch.
    • 2.1 D 4X4: 58 ch.

    gasoline

    • 1.4: 48 ch.
    • 1.6: 65 ch.
    • 1.6 4X4: 65 ch.
    • 1.7: 68 ch.
    • 2.0: 79 ch.
    • 2.0: 80 ch.
    • 2.0 4X4: 80 ch.

    Bus Version 1989 to 2001

    Diesel

    • 1.9 D: 60 ch.
    • 2.1 D: 58 ch.
    • 2.1 D: 64 ch.
    • 2.5 D: 75 ch.
    • 2.5 D 4X4: 75 hp

    gasoline

    • 1.7: 68 ch.
    • 2.0: 80 ch.
    • 2.2: 95 ch.
    • 2.2: 101 ch.

    Platform / Chassis version 1980 to 1989

    Diesel

    • 2.1 D: 58 ch.
    • 2.1 D 4X4: 58 ch.
    • 2.1 D: 60 ch.
    • 2.5 D: 69 ch.

    gasoline

    • 1.4: 48 ch.
    • 1.6: 65 ch.
    • 1.7: 68 ch.
    • 2.0: 80 ch.
    • 2.0 4X4: 82 ch.
    • 2.0: 86 ch.

    Platform / Chassis version 1989 to 2001

    Diesel

    • 2.1 D: 58 ch.
    • 2.1 D: 64 ch.
    • 2.5 D: 69 ch.
    • 2.5 D: 75 ch.
    • 2.5 D: 76 ch.
    • 2.5 D 4X4: 76 ch.
    • 2.5 D: 79 ch.
    • 2.5 D 4X4: 79 ch.

    gasoline

    • 1.7: 68 ch.
    • 2.0: 80 ch.
    • 2.0: 82 ch.
    • 2.2: 95 ch.
    • 2.2: 95 ch.
    • 2.2 4X4: 101 ch.

    Van version 1980 to 1989

    Diesel

    • 2.1 D: 58 ch.
    • 2.1 D 4X4: 58ch.

    gasoline

    • 1.4: 48 ch.
    • 1.6: 65 ch.
    • 1.6 4X4: 65 ch.
    • 1.7: 68 ch.
    • 2.0: 79 ch.
    • 2.0: 80 ch.
    • 2.0 4X4: 80 ch.
    • 2.0: 82 ch.

    Van version 1989 to 2001

    Diesel

    • 1.9 D: 60 ch.
    • 2.1 D: 58 ch.
    • 2.1 D: 64 ch.
    • 2.5 D: 75 ch.
    • 2.5 D 4X4: 75 hp

    gasoline

    • 1.4: 48 ch.
    • 1.7: 68 ch.
    • 2.0: 80 ch.
    • 2.2: 95 ch.
    • 2.2 4X4: 95 ch.
    • 2.2: 101 ch.
    • 2.2 4X4: 101 ch.

Service

Service
  • Engine: Renault Trafic I 2.0L Petrol
    Compression ratio - 9.2:1
    Ignition system - SZ
    Fuel system - Solex Type 32 SEIA
    Firing order - 1-3-4-2
    Distributor - Ducellier No R243'D61
    Valve clearance -INLET  0.10mm (check cold)
    Valve clearance -EXHAUST 0.25mm (check cold)
    Oil pressure - 3 Bar @ 3000rpm
    Engine oil grade - normal climate 15W/40 SAE
    Engine oil change - 5.3 litres
    Brake fluid - DOT 4 0.7 litres

    Note:
    All engines and full specifications available for registered users
