Standard Ten
![]() | |
Also called | Standard Companion Standard 6 cwt Standard Vanguard Junior Triumph TR-10 |
---|---|
Production | 1954–1960 172,500 made |
Assembly | United Kingdom Australia |
Body style | 4-door saloon 4-door estate car 2-door coupe utility 2-door panel van |
Engine | 948 cc Straight-4 ohv |
Transmission | Four speed manual optional overdrive |
Wheelbase | 84 inches (2134 mm) |
Length | 144 inches (3658 mm) |
Width | 60 inches (1524 mm) |
Height | 60 in (1,500 mm) |
The Standard Ten was a small car produced by the British Standard Motor Company (discontinuously) from 1906 to 1961.
The name was first used in 1906 as the 10 hp, with a 631 cc 2-cylinder side-valve engine. It was re-used from 1934 to 1936 and again for the "Flying 10" launched in 1937, and produced until the outbreak of World War II. The name originally was a reference to the car's fiscal horsepower, in turn a function of the surface area of the pistons, and never a direct measure of the power produced by the engine. Like other manufacturers, Standard continued to use the name to define the approximate size of their 'Ten' model long after the origins of the name had, in Britain, become inapplicable.
The Ten and its up-market sibling, the Pennant, were replaced by the Triumph Herald in 1961.
In 1954 the Ten was introduced as a larger-engined (and less basic) version of the Standard Eight, though sharing a similar frame and transmission. Overdrive (from March 1957) or a temperamental semi-automatic were available as options. An estate (station wagon) version, the Companion was launched in 1955. It was among the first small British estate cars to have rear-passenger doors (like the saloon, and unlike its rivals such as the Ford Squire and Hillman Husky which used the two-door "van" arrangement).
A small number of left-hand-drive Tens were exported to the USA and sold as the Triumph TR-10. On these, the two-tone colour arrangement normally reserved for the Pennant was available (though this export model was not tailfinned).
A Ten saloon tested by the British magazine The Motor in 1954 had a top speed of 69.0 mph (111.0 km/h) and could accelerate from 0-60 mph (97 km/h) in 38.3 seconds. A fuel consumption of 34.4 miles per imperial gallon (8.21 L/100 km; 28.6 mpg-US) was recorded. The test car cost £580 including taxes.
In 1955, supported by an inscrutable handicapping régime favouring small cars, a factory-prepared Standard Ten, driven by Jimmy Ray and Brian Horrocks, won the UK's RAC Rally
For the United States export market the car was badged as the Triumph Ten and in Scandinavia it was sold as the Standard Vanguard Junior. In Australia the Ten was known as the Cadet The Family best described as a ten-engined Super Eight, for it Consists of the 948-c.c. engine in the Super Eight body shell. The main difference between the Family Ten and the Super Ten is, therefore, the absence of an opening luggage boot lid on the Family model.
STANDARD SUPER TEN PHASE II Obtainable with the Standrive clutchless gear change as an optional extra, the Standard Super Ten was the first British small car to be offered with two-pedal control. The Phase Il model differs from the Phase I in having a raised compression ratio, improved interior trim, and a chromium moulding strip along the body sides.
Description
Technical
-
Standard Ten Technical details and specifications (1954-1960)
DIMENSIONS AND WEIGHT:
Wheelbase, 7ft (213 cm)
widest track, 4ft Oin (123 cm)
Overall length, 12ft 1in (368 cm)
width, 4ft 10in (147 cm)
height, 5ft (152 cm)
ground clearance, 6.5in (16 cm).
Turning circle, 32 ft (975 cm).
Weight (approx.), 1,596 1b (725 kg).
Tank capacity, 7 Imperial gallons (31.82 litres).ENGINE:
No. of Cylinders - 4
R.A.C. Rating - 9-9 h.p.
Cubic capacity - 948 c.c.
B.H.P. (Net) - 37 at 5,000 r.p.m.
Bore - 63mm. (2-48in.)
Stroke - 76mm. (2-992in)
Compression Ratio - 8-0 to 1
System of Cooling - Pump, thermostatically controlled, pressurised
Firing order - 1-3-4-2
No. of compression rings - 2
No. of oil rings - 1
Oil pressure, lb. sq. in. - 40 to 60
Gudgeon pin type - Fully floating
No. of crankshaft bearings -3
Type of bearings Main - Precision, steel-backed, w. metal lined
No. of Camshaft bearings - 4
Camshaft drive (type) - Duplex chain
Carburettor make & type - solex 28ZIC/2TRANSMISSION DRIVE LINE:
4 speeds
synchromesh
Clutch type - Single dry plate, Borg & Beck
Gear ratio, top - 4.555
Gear ratio, third - 6.62
Gear ratio, second - 11.20
Gear ratio, first - 19.45
Gear ratio, reverse - 19.45
Type of axle - Semi-floating
Type of drive - Hypoid
Ratio 4.55 to 1SUSPENSION:
independent front, coil springs; 1/2-elliptic rear.
Front - Independent, coil springs Rear - Semi-ellipticBRAKES:
Girling hydraulic Type
Lining size—Front - 7 X 1 1/4 in. Area 34 sq.in.
Lining size—Rear - 7 X 1 1/4 in. Area 34 sq.in.
two-leading shoe front, leading and trailing.ELECTRICAL EQUIPMENT:
Battery, 12-volt, 38 a/h.
Battery—Capacity,Make,type - 12v. 38 a.h. Lucas BT7A
Battery earth—pos or neg - PositiveWHEELS TYRES:
Tyre size, 5.60—13in.
© Motor car History
-
Standard Ten Maintenance and Service Guide (1954-1960)
Tyre size and pressures - 5-20 x 13in. .
Tyre pressures 22 1b
Distributor rotation - Anti-clockwise
Manual advance - Micro. adjustment
Automatic advance - Centrifugal and suction
Breaker gap - .015in.
Plug make and type - Champion NA8
Plug gap - .032in.
Firing order - 1-3-4-2
Ignition timing—degrees - 10° B.T.D.C.
Valve timing markings - Scribed marks on sprockets
Exhaust Valve diam.— Head and Stem - 1-058 to 1-054in. & .3090 to .3080in.
Inlet Valve diam.—Head and Stem -1-183 to 1-179in. & .3110 to .3100in.
Tappet type - Flat based, chilled C.I.
Inlet Valve clearance for timing -.0165in.
Inlet Valve opens—degrees - 10° B.T.D.C.
Inlet Valve clearance-.010in. cold
Exhaust Valve clearance-.010in. coldCAPACITIES (Imperial)
Sump - 7—pints
Gearbox - 1.5—pints
Rear Axle - 1.5—pints
Cooling system - 7 to 8—pints
Petrol - 7—galls© Motor car History
