VW Amarok
 | |
Production : | 2010 on |
Class : | commercial |
Body versions : | Pick up |
Engines: | Gasoline :2.0 liters (118 kW) |
Length: | 5191-5254 mm |
Width: | 1944-1954 mm |
Height: | 1834-1878 mm |
Wheelbase : | 3090-3095 mm |
Curb weight : | 1872-2324 kg |
The VW Amarok is a pickup model from Volkswagen . Built from 2010 on .With 4 out of 5 Stars in the Euro NCAP crash test.
History
The Amarok pickup model, with the exception of the USA and Canada, is distributed worldwide.An annual production of 40,000 vehicles at the Hannover plant (double cab only) began for the European markets as well as for the Russian market at the end of June 2012. The Amarok is based directly on the concept vehicle , which was presented for the first time at the IAA for commercial vehicles in 2008.The Amarok name is a wolf-like creature in the mythology of the Eskimos . The VW Amarok was officially seen as the official escort vehicle of the Dakar Rally in Chile and Argentina in January 2010.
The Amarok pickup model number VWN817 is 5.25 meters long, has a double cabin and a loading area of 2.52 square meters. Since spring 2011, there is also a version with a single cabin and a correspondingly longer loading area. The loading platform is 1.55 meters long in the double cabin. The payload is up to 1.15 tons. In the Euro NCAP crash test in November 2010, the VW Amarok achieved 31 points (86%) in occupant protection and 17 points (47%) in pedestrian protection. In the overall ranking he received four out of five stars.
Optionally, a 2.0-liter 120 kW (163 hp) bi-turbo diesel engine or a 90 kW (122 hp) 2.0 l turbo diesel engine is available. The base model has rear-wheel drive. On request, a permanent four-wheel drive or manually engageable four-wheel drive with reduction and differential lock the rear axle is available (Shiftable 4Motion and Permanent 4Motion). The vehicle has a box frame , one at the front double wishbones with spring dampers suspended wheels, a steering rack and a suspended on leaf springs rigid rear axle. Front there are ventilated disc brakes, rear drum brakes.
Since fall 2011, a rear hardtop can be ordered directly from the manufacturer. In January 2012, the Amarok also came in Australia with the 2.0-liter TSI engine with 118 kW (160 hp) and rear-wheel drive.
In September 2016, a revised version of the Amarok came on the market. Since then, the engine has been powered by a three-liter V6 diesel engine, which also powers the Audi A6 or the VW Touareg . This engine is used in the Amarok in three power levels between 120 kW (163 hp) and 165 kW (224 hp), with the weakest being available only since spring 2017. Reason for the change is the lack of Euro 6 capability of the previous unit, which is also mandatory for light commercial vehicles since September 2016. For the 2017 model year, Volkswagen announced a facelifted Amarok range.
Rating
Technical
-
VW Amarok Technical data
2.0 TD I
2.0 TD I 4Motion
2.0 TD I
2.0 TD I 4Motion
2.0 T DI
2.0T DI 4Motion
2.0 T DI
2.0T DI 4Motion
3.0 TDI
3.0 TDI 4Motion
2.0 TSI
Construction period
03 / 2010-11 / 2012
11 / 2012-06 / 2016
03 / 2010-05 / 2012
06 / 2012-09 / 2016
11 / 2011-09 / 2016
since 09/2017
since 09/2016
09 / 2016-04 / 2018
since 04/2018
since 01/2012 *
motor series
VW EA189, VW EA288
VW EA897 evo
engine type
Four-cylinder diesel engine in serial construction , common-rail injection
Six-cylinder diesel engine in V-type , common-rail injection
Four-cylinder gasoline engine in series design , direct injection
engine charging
turbocharger
BiTurbo
turbocharger
capacity
1968 cm³
2967 cc
1984 cm³
Max. Power at min -1
90 kW (122 hp) / 3750
103 kW (140 hp) / 3500
120 kW (163 hp) / 4000
132 kW (180 hp) / 4000
120 kW (163 hp) / 2750-4500
150 kW (204 hp) / 3000-4500
165 kW (224 hp) / 3000-4500
190 kW (258 hp) / 3250-4500
118 kW (160 hp) / 3750
Max. Torque at min -1
340 Nm / 1750-2250
340 Nm / 1600-2250
400 Nm / 1500-2000
400 Nm / 1500-2250 (420 Nm / 1750) **
450 Nm / 1250-2500
500 Nm / 1250-2750
550 Nm / 1400-2750
580 Nm / 1400-3000
300 Nm / 1600-3750
Drive type, standard
rear-wheel drive
all wheel drive
rear-wheel drive
all wheel drive
rear-wheel drive
all wheel drive
rear-wheel drive
all wheel drive
rear-wheel drive
all wheel drive
rear-wheel drive
Gearbox type, standard
6-speed manual transmission
6-speed manual transmission
8-speed automatic transmission
6-speed manual transmission
Transmission type, optional
-
8-speed automatic transmission
-
8-speed automatic transmission
-
tare
1872-2064 kg
1948-2168 kg
1797-2248 kg
1875-2345 kg
1882-2074 kg
1958-2178 kg
1911-2178 kg
2005-2178 kg
2069-2177 kg
2010-2145 kg
2078-2095 kg
2241-2324 kg
1737-1842 kg
maximum payload
778-1147 kg
673-1057 kg
572-1243 kg
475-1165 kg
768-1137 kg
663-1047 kg
743-831 kg
545-1053 kg
596-679 kg
545-985 kg
Trailer load, braked
2800 kg
2800-3000 kg
2800 kg
2800-3000 kg
2900-3000 kg
3300-3500 kg
3500 kg
3000 kg
Acceleration 0-100 km / h
13.5 s
13.7 s
12.6-13.3 s
12.6-13.5 s
10.8 s
11.1 s
10.0-10.7 s
10.3-11.0 s
9.6-10.0 s
8.3-9.2 s
7.9-8.2 s
7.3-7.6 s
k. A.
top speed
163 km / h
161 km / h
163-169 km / h
161-167 km / h
182 km / h
181 km / h
178-184 km / h
177-179 km / h
171-180 km / h
182-193 km / h
185-193 km / h
199-207 km / h
Fuel consumption
per 100 km (combined)7.3-7.4 l diesel
7.4-7.6 liters of diesel
6.8-7.7 liters of diesel
7.0-7.8 l diesel
7.6-7.7 liters of diesel
7.8-7.9 liters of diesel
7.4-7.5 liters of diesel
7.3-8.2 liters of diesel
8.1-9.2 liters of diesel
7.6-9.2 liters of diesel
8.0-8.9 liters of diesel
8.4 l diesel
9.5-9.6 Super
CO 2 emission, combined
192-194 g / km
194-199 g / km
179-202 g / km
185-205 g / km
199-203 g / km
206-209 g / km
185-194 g / km
187-203 g / km
213-242 g / km
199-241 g / km
210-233 g / km
220 g / km
226-228 g / km
Emission standard according to EU classification
5 euro
Euro 6
Euro 4
* Australia
** with 8-speed automatic transmission 420 Nm / 1750
Production figures
year
2008
2009
2010
2011
2012
2013
2014
2015
2016
2017
2018
number
-
193
44525
76965
78633
91739
69695
81019
63367
80328
88950
